TECHNICAL SPECIFICATIONS

Antenna type: parabolic antenna (2-pieces )
Frequency range: 940 - 960 MHz
Bandwidth: 20 MHz
Gain: 21.5 dBi
Front-to-back ratio: > 30 dB
VSWR: < 1.3
Impedance: 50 ohms
Polarization: Horizontal or Vertical
Power rating: 100 Watts
H-PLANE Beamwidth: 11 degrees (half-power)
E-PLANE Beamwidth: 11 degrees (half-power)
Connector: N type Female
Diameter: 6 ft (1.8 mt)
Windload: 125 MPH

Elevation Adj Range: + or - 5 degrees

Weight: 31 lbs (14 Kg)
Dimensions: 75"×75"×27" (1905×1905×685mm)
Pkg Dimensions & Weight: 73"x39"x18"  60lbs
Mounting: from 1.5" to 3"
Lightning protection: all parts grounded

This is a folded edge anodized aluminum parabolic antenna particularly suitable for STL systems. Due to its narrow radiation pattern, this antenna has excellent front-to-back and front-to-side ratios minimizing the possibility of interference from other stations. Because of its high directivity and gain this antenna is well suited for long distance STL links.

Overview: Heavy Duty 900MHz Parabolic STL Directional Antenna 6 Feet

900MHz band for STL Applications

Directional Grid Parabolic Antenna

High Gain, Heavy Duty, 6ft diameter

optional radome

Hardware

BKP180 HD Patterns

Note: Please contact us for specific bay system wavelength studies.
